T9831/2/3 Analogue Input Termination Assembly Specification
Table 28: Analogue Input Termination Assembly
Attribute Value
Functional Characteristics
Field connections 16
Number of input modules supported
T9831 One
T9832 Two
T9833 Three
Electrical Characteristics
Input channel fuses 50mA per channel
Channel load 135  ± 2 
Channel isolation:
T9831 None
T9832/T9833 ± 1.5kV dc Maximum withstanding for 1 minute
Maximum field loop power dissipation 0.08W per field loop (0.27BTU/hr)
Mechanical Specification
Dimensions (height × width)
T9831 132mm × 42mm (5-¼ in. × 1-21/32 in.)
T9832 132mm × 84mm (5-¼ in. × 3-5/16 in.)
T9833 132mm × 126mm (5-¼ in. × 5 in.)
Weight
T9831 133g (5oz)
T9832 260g (10oz)
T9833 360g (13oz)
