9.4.1 Moving a Cursor

You can select a cursor by:

•

clicking on the cursor label with the mouse

•

using the Cursor menu

•

using the [Tab] key

Move the cursors by:

•

using the up, down, right, and left arrow keys or Shift + arrow key

•

clicking on the label with the mouse and dragging the cursor

9.4.2 Specifying the Cursors To Track Each Other

You set the cursors to track together when you move them. This way the cursors can
move left and right and up and down while maintaining the same distance between T1
and T2 or Y1 and Y2.

To set the T and Y cursors so they track together:

•

From the Cursor menu, choose Track or click

Turning track off lets you move the T cursors independently from each other and the Y
cursors independently from each other. Cursor tracking can be turned on and off by
toggling the menu selection or toolbar button.

9.5

Changing Views

You can turn the cursors on and off and magnify the trace display as described in the
following sections.

9.5.1 Turning Cursors On and Off

You can choose to show or not the show the cursors on the trace display.

To turn cursors on or off:

•

From the View menu, choose Cursors or click

You cannot use the Zoom feature if the cursors are off.
