1756 ControlNet Status Indicators
Appendix A
Any
Keeper: Unconfigured
The network configuration data maintained in memory by the keeper object has been erased or
corrupted.
Do any of the following:
• Use RSNetWorx software to download or update the keeper object in the module.
• Reset the module to the original factory settings, as described on
.
Keeper: Unconfigured (data format
changed)
The network configuration data maintained in memory by the keeper object is in a format
incompatible with the current revision of firmware.
Do any of the following:
• Use RSNetWorx software to download or update the keeper object in the module.
• Reset the module to the original factory settings, as described on
.
Keeper: Unconfigured (slot changed)
After the keeper object’s network-configuration data was downloaded, the module was moved to a
different spot in the rack.
Do any of the following:
• Return the module to the proper slot.
• Use RSNetWorx software to download or update the keeper object in the module.
• Reset the module to the original factory settings, as described on
.
Keeper: Unconfigured (net address
changed)
The network address switches on the module have been changed since the keeper object’s
network-configuration data was downloaded.
Do any of the following:
• Return the network address switches to their original setting.
• Use RSNetWorx software to download or update the keeper object in the module.
• Reset the module to the original factory settings, as described on
.
Keeper: Signature Mismatch
The network configuration data maintained in memory by the keeper object does not match the
current network configuration.
There is a valid active keeper on the network.
Do any of the following:
• Use RSNetWorx software to download or update the keeper object in the module.
• Reset the module to the original factory settings, as described on
.
Keeper: None Valid on Network
The network configuration data maintained in memory by the keeper object does not match the
current network configuration, and there is no valid active keeper on the network.
Use RSNetWorx software to download or update the keeper object in the module.
Important: The
procedure does not work. There is no valid active
keeper from which to crossload data.
(1) ControlLogix enhanced redundancy systems only.
Table 1 - OK Status Indicator and Display
Status
Display
Description
