Publication 4100-5.2 - June 1998
39
Encoder Output Specifications
The table below details the electrical specifications of the encoder
output.
Figure A.7
Marker Output
Supported resolver packages
1326AB-MOD-VD1:x single resolver
package.
x = rotor to input shaft ration
x = 1, 2, 2.5, or 5
1326AB-MOD-VD:256/255 dual
resolver package.
256/255 is the master to vernier gear
ratio.
Use cable 1326AB-CVUxx for the
specified Bulletin 1326 resolver
packages above.
xx = length in feet (100 ft. maximum)
846-SJ abcd-R2-e single resolver
package.
a = mounting configuration
b = connector style
c = connector location
d = gear ratios
R2 = Harlowe resolver element
11BRCX-300-C or equivalent. e
replaces c if mating connector is
supplied.
Use cable 845AB-CA-i-xx
xx = length in feet (up to 100 ft.)
Strobe Inputs:
Type
Source Impedance
Maximum active Voltage
Minimum Inactive Voltage
Current Sourcing Active Low
10k Ohm
0.6V DC
2.2V DC
Specification Description
Number of encoder outputs 2 (0 and 1)
Type of encoder output Incremental quadrature with marker, EIA RS 422 level
Equivalent line count 4096 counts under 4X decode mode
Maximum update rate 1.6 MHz
Marker output Synchronized 180 degrees to A channel. See figure A.2
for a picture of the output for the three channels
Specification Description
