Rockwell Automation 6189x Integrated Display Industrial Computers User Manual User Manual
Page 25
Rockwell Automation Publication 6181P-UM003A-EN-P - May 2014
25
Installation
Chapter 2
Figure 8 - 1200P (12-inch) Standard Display Computer
Figure 9 - 1500P (15-inch) Standard Display Computer
115 (4.53)
349 (13.74)
103 (4.06)
72 (2.83)
14.5 (0.57)
320 (12.60)
115 (4.53)
279
(10.98)
251
(9.88)
145 (5.71)
408.9 (16.1)
28 (1.1)
320 (12.6)
33.4
(1.31)
15.8
(0.62)
33.4
(1.31)
145 (5.71)
14.5 (0.57)
103 (4.06)
15.8
(0.62)
251
(9.88)
309
(12.16)
IMPORTANT: 1500P models with stainless
steel bezels do not have the front USB port
at right, status indicators in the upper right,
or the UIB below.
