FLEX Ex 8 Input Analog, HART, and Noise Filter Analog Modules 29
Publication 1797-5.5 - September 2011
HART Status
Indicators When this bit is set (1), the status indicators are used for HART
diagnostic. Indicator behavior changes to show communication on
HART. Each indicator represents a HART loop. Flashing yellow indicates
that communication is currently being processed. Solid yellow means
that this device is in the transmitter list.
HART Status Inhibit When this bit is set (1), the HART communication status is not shown in
the realtime data table. The appropriate areas are cleared with zeroes.
Range: 0 = normal, 1 = inhibit HART
50/60 Hz Filter Range: 0 = 50 Hz, 1 = 60 Hz
Field Descriptions
