FLEX Ex 8 Input Analog, HART, and Noise Filter Analog Modules 21
Publication 1797-5.5 - September 2011
22 Low Alarm Limit Ch3
23 High High Alarm Limit (Remote) Ch3
24 Low Low Alarm Limit (Remote) Ch3
25 High Alarm Limit Ch4
26 Low Alarm Limit Ch4
27 High High Alarm Limit (Remote) Ch4
28 Low Low Alarm Limit (Remote) Ch4
29 High Alarm Limit Ch5
30 Low Alarm Limit Ch5
31 High High Alarm Limit (Remote) Ch5
32 Low Low Alarm Limit (Remote) Ch5
33 High Alarm Limit Ch6
34 Low Alarm Limit Ch6
35 High High Alarm Limit (Remote) Ch6
36 Low Low Alarm Limit (Remote) Ch6
37 High Alarm Limit Ch7
38 Low Alarm Limit Ch7
39 High High Alarm Limit (Remote) Ch7
40 Low Low Alarm Limit (Remote) Ch7
41 HR
Ch7 HR
Ch6 HR
Ch5 HR
Ch4 HR
Ch3 HR
Ch2 HR
Ch1 HR
Ch0 HCD
Ch7 HCD
Ch6 HCD
Ch5 HCD
Ch4 HCD
Ch3 HCD
Ch2 HCD
Ch1 HCD
Ch0
Where NF: notch filter (50/60 Hz) HCD: HART CMD3 disable
FE: fault enable VR: verify replacement
HS LED: HART status LEDs HSI: HART status inhibit
HD: HART disable HHE: HART handheld enable
HR: HART rebuild
(1) Group B and Group A “Not used in some controller software”
1797-IE8H Configuration Map
Word Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
