38 Rockwell Automation Publication 2080-QS002A-EN-E - April 2013
Appendix A MSG_CIPSYMBOLIC Function Block
Status Output CIPSTATUS Instruction execution status. When a MSG is triggered (or re-triggered), all elements inside Status
are reset. This is a structured data type. It consists of the following elements:
• Status.Error (Boolean)
This bit is set to TRUE when function block execution encountered an error condition.
• Status.ErrorID (UINT)
Error code value. See CIP Error Message Codes on page 45 .
• Status.SubErrorID (UDINT)
Sub Error code value. See CIP Error Message Codes on page 45 .
• Status.ExtErrorID (UINT)
CIP extended status error code value
• Status.StatusBits (UINT)
This parameter can be used to verify various control bits.
- Bit 0: EN – Enable
- Bit 1: EW – Enable Wait
- Bit 2: ST – Start
- Bit 3: ER – Errors (same state as Q)
- Bit 4: DN – Done (same state as Q)
- Other bits are reserved.
DataLength Output UINT CIP read message response data length and CIP write message request data length (Unit: Byte).
When a read MSG is triggered (or re-triggered), ResLength is reset to 0.
Range: 0...490
MSG_CIPSYMBOLIC Parameters
Parameter Parameter
Type Data Type Description
