26 Installation
Connect a Keyboard and
Mouse
You can connect a USB keyboard and/or mouse to the USB ports on
the computer. On the non-display computers, you can also connect a
keyboard or mouse to the PS/2 port.
Connect the Video
A video loopback cable is shipped with the display computers. The
loopback cable connects between the VGA Video Output connector
and the Screen Display Input connector on the computer. You must
connect this cable to view images on the front panel display of the
computer.
To PS/2 Port on the Non-display Computer
IMPORTANT
Images will not appear on the front panel display if the video
loopback cable is not connected.
Screen
Display
Input
VGA Video Output
