14 System Features
1500W and Non-display Workstations - Top and Side
1500W and Non-display Workstations - Side View
LCD Display
(with or without
optional touchscreen)
Alpha Keys
32 Function Keys
Numeric Keys
USB Ports
Printer
LAN
Screen Display Input
(display only)
VGA Output
COM1
Floppy Disk
Drive
Optical Drive
Power
Power Switch
PS2 Keyboard/Mouse
Port (non-display only)
Audio Output
Screen Auto Adjust Button (display only)
