APPLYING THE MODULE
5-5
5.3
Initialization
The following example illustrates the software required to
initialize one axis. The variables reference the configuration
data in Appendix H.
1000
!
1010
! Initialize Axis Parameters
1020
!
2000
ENCODER_SETUP%=01414H\!Rotary, polarity reversed, *4
2010
DRIVE_SETUP%=02H
\!Polarity reversed, current ref
2020
SWITCHES%=01DH
\!Marker pulse, home negative
2030
PGAIN%=18700
\!Position Gain
2040
IGAIN%=1575
\!Integral Gain
2050
VGAIN%=140 \!Velocity Gain
2060
FGAIN%=8256
\!V Feedforward Gain
2070
DBCOMP%=27
\!Deadband Compensation
2080
MAX_FOLL_ERR%=1000
\!Maximum following error
2090
MAX_VEL_ERR%=8
\!Maximum velocity error
2100
IN_TOLERANCE%=40
\!In position tolerance
2110
GEAR_RATIO!=16777216
\!Gear ratio
2120
MAX_VOLTS%=1984
\!Maximum drive reference value
2130
P_CONST%=-1
\!Positive linearization constant
2140
N_CONST%=-1
\!Negative linearization constant
2150
FDBK_UNWIND!=4000
\!V Fdbk unwind = 1 revolution
2160
GEAR_UNWIND!=4000
\!Gearing unwind = 1 revolution
2170
MODES%=0
2180
CMD66%=0200H\GOSUB 25000\!Change default setups
2190
!
10000
!
24997
!
24998
! Subroutine to write command to module
24999
!
25000
DELAY 2 TICKS \IF NOT (CMD_ACK@ OR ILLEGAL_CMD@)
THEN GOTO 25000
25005
FAULT
@=
ILLEGAL_CMD@
25010
CMD66%=0 \CMD67%=0
25015
DELAY 2 TICKS \IF CMD_ACK@ THEN GOTO 25015
25020
RETURN
30000
END
