MECHANICAL / ELECTRICAL DESCRIPTION
2-1
C
HAPTER
2
MECHANICAL /
ELECTRICAL
DESCRIPTION
The following is a description of the faceplate LEDs, field
termination connectors and electrical characteristics of the
field connections.
2.1
Mechanical Description
The 2-Axis Servo module is a printed circuit board assembly
that plugs into the backplane of the DCS 5000/AutoMax rack.
It consists of the printed circuit board, a faceplate, and a
protective enclosure. The faceplate contains tabs at the top
and bottom to simplify removing the card from the rack.
Assembly dimensions are listed in Appendix A.
The faceplate of the module contains a 37-pin D-shell
connector socket and eight LED status indicators for each
axis. It also contains three LEDs that can be controlled from
the application software. Refer to figure 2.1.
