Rockwell Automation 1797-ACNR15 ControlNet Ex Redundant Media Adapter User Manual
Page 26
26 ControlNet Ex Redundant Media Adapter
Publication
1797-5.14 - March 2010
Comm A or Comm B Individually
Off
Channel disabled
Green
Channel operational
Flashing Grn/Off
Temporary network errors
Flashing Red/Off
Cable fault, broken cable, redundancy warning
Flashing Red/Grn
Bad network configuration
Status Indicator
Off
No power
Flashing Grn
Online, but not connected
Green
Online, link okay, connected
Flashing Red
I/O module removed, wrong I/O module inserted, FLASH program
update in progress
Red
Critical - adapter failure
Module Status
Steady Green
At least one connection is established
Flashing Green
No connections are established
Flashing Red
Module removed, wrong module reinserted, or flash update in
progress
Steady Red
Bad adapter
Power
Steady Green
Power is applied to the module
