Scanner Commands
Appendix F
F–2
Serial Communication Parameters
Mnemonic
Function
Page #
DA
Baud Rate = 300
6-2
DB
Baud Rate = 600
6-2
DC
Baud Rate = 1200
6-2
DD
Baud Rate = 2400
6-2
DE
Baud Rate = 4800
6-2
DF
Baud Rate = 9600
6-2
DG
Baud Rate = 19200
6-2
EA
7 Data Bits, 1 Stop Bit, Space Parity
6-4
EB
7 Data Bits, 1 Stop Bit, Mark Parity
6-4
EC
7 Data Bits, 1 Stop Bit, Even Parity
6-4
ED
7 Data Bits, 1 Stop Bit, Odd Parity
6-4
EE
7 Data Bits, 2 Stop Bits, Space Parity
6-5
EF
7 Data Bits, 2 Stop Bits, Mark Parity
6-5
EG
7 Data Bits, 2 Stop Bits, Even Parity
6-5
EH
7 Data Bits, 2 Stop Bits, Odd Parity
6-5
EI
8 Data Bits, 1 Stop Bit, Space Parity
6-6
EJ
8 Data Bits, 1 Stop Bit, Mark Parity
6-6
EK
8 Data Bits, 1 Stop Bit, Even Parity
6-6
EL
8 Data Bits, 1 Stop Bit, Odd Parity
6-6
EM
8 Data Bits, 1 Stop Bit, No Parity
6-5
EN
8 Data Bits, 2 Stop Bits, No Parity
6-6
HA
CTS Protocol = None
6-8
HB
Protocol = XON/XOFF
6-8
HC
Protocol = CTS(+)
6-8
HD
Protocol = CTS(–)
6-8
HG
RTS always high
6-9
HH
RTS always low
6-9
HI
RTS high means scanner has data to transmit
6-9
HJ
RTS low means scanner has data to transmit
6-9
HK
RTS low means scanner ready to receive data
6-9
GA
No Intercharacter Delay
6-10
GB
Set Intercharacter Delay
6-10
NE
Serial Transmit Buffer = Full Buffering
6-11
NF
Serial Transmit Buffer = No Buffering
6-11
NG
Serial Transmit Buffer = One Label Buffering
6-11
