Specifications
Appendix A
A-3
Touch Cell Format
matrix of 120 touch cells (10 across by 12 high)
each touch cell is 2 characters high by 8 characters wide
user can configure/group cells to any size buttons
Touch cells are rated for 1,000,000 presses.
The following tables provide details of the display specifications.
Display Format
24 Rows x 80 Columns (normal size characters)
Character Cell Pixel Format 8 wide x 10 high
Display Alignment
UserĆconfigurable, stored in nonĆvolatile memory, 12 character
horizontal range, 2.4 character vertical range
Display Intensity
Low to high range adjustment on back of unit
Screen Saver
UserĆconfigurable, 1Ć999 minute timeout
Display Size
12" Diagonal
Color Unit Display Attributes
You select 8 from a palette of 16 colors.
ББББББББ
ББББББББ
Black
ББББББББ
ББББББББ
Grey
ББББББББ
ББББББББ
White
ББББББББ
ББББББББ
Bright White
ББББББББ
ББББББББ
Red
ББББББББ
ББББББББ
Bright Red
ББББББББ
ББББББББ
Blue
ББББББББ
ББББББББ
Bright Blue
ББББББББ
ББББББББ
Green
ББББББББ
ББББББББ
Bright Green
ББББББББ
ББББББББ
Magenta
ББББББББ
ББББББББ
Bright Magenta
ББББББББ
ББББББББ
Cyan
ББББББББ
ББББББББ
Bright Cyan
ББББББББ
ББББББББ
Yellow
ББББББББ
ББББББББ
Bright Yellow
Foreground/background color for individual screen objects and functions
can be assigned any of the above. However, some colors do not appear
exactly the same on a PanelView 1200 terminal as they do on the
development computer. You may find, as well, that white appears to be
light grey and grey appears to be black if they are contrasted with certain
other colors. For these reasons, you may find that you achieve the best
results if you reserve the colors in the right hand column for foreground
colors only.
CRT Display
