46 DeviceLogix for POINT I/O and ArmorPOINT I/O on Ethernet/ControlNet
I/O Tags
The following table lists the input tags and their descriptions.
The following table lists the output tags and their descriptions.
Input tags and their descriptions
Tag
Description
Data
This will contain the state of eight I/O points. See
details.
LogicDefinedData
These eight bits are assigned using the Network Output Bit tags
in the DeviceLogix program.
LogicEnabled
When set, the DeviceLogix program is running.
Owned
When set, the module is owned by a master.
PeerMissing
Each bit represents one of the eight possible peers. If a bit is
set, the data from that peer is missing or invalid.
LogicDefinedData[]
These eight values are assigned using the Network Output
Word tags in the DeviceLogix program.
Output tags and their descriptions
Tag
Description
Data
This value is sent by the master to set the output state of the
eight output points. This can be overwritten if the Devicelogix
program is controlling the outputs (Logic Enable On).
See
for details.
LogicDefinedData
These eight bits can be used in the DeviceLogix program with
the Network Input Bit tags.
LogicDefinedIntData[]
These eight values can be used in the Devicelogix program with
the Network Input Word tags.
