Publication 1734-UM015A-EN-E - November 2009

DeviceLogix for POINT I/O and ArmorPOINT I/O on DeviceNet 39

I/O Data Assembly Maps

Read this section for information about how to communicate with your
module.

I/O messages are sent to (consumed) and received from (produced) the I/O
modules. These messages are mapped into the processor’s or scanner’s
memory. Each module produces 1, 8 or 20 bytes of input data based on which
produced assembly is selected. The default setup is 20 bytes.
It consumes 1, 8 or 20 bytes of I/O data (scanner Tx).

Default Data Map - Produced Assembly Instance 101

Message Size: 20 Bytes

Bit

7

6

5

4

3

2

1

0

Data [0]

Pt 07

Pt 06

Pt 05

Pt 04

Pt 03

Pt 02

Pt 01

Pt 00

Data [1]

PNB 07

PNB 06

PNB 05

PNB 04

PNB 03

PNB 02

PNB 01

PNB 00

Data [2]

Reserved

Owned

LogicEn

Data [3]

PM7

PM6

PM5

PM4

PM3

PM2

PM1

PM0

Data [4]

Produced Network Analog Word 0

Data [5]

Data [6]

Produced Network Analog Word 1

Data [7]

Data [8]

Produced Network Analog Word 2

Data [9]

Data [10]

Produced Network Analog Word 3

Data [11]

Data [12]

Produced Network Analog Word 4

Data [13]

Data [14]

Produced Network Analog Word 5

Data [15]

Data [16]

Produced Network Analog Word 6

Data [17]

Data [18]

Produced Network Analog Word 7

Data [19]

Where:

Pt = value of the I/O point,

PNB = Produced Network Bit,

PM = Peer Missing (a 1 indicates the absence of a configured peer)

Owned = Owned by a master.
When set to 0, the module is producing data without a master.
When set to 1, the module is producing while being owned by a master.

LogicEn = Logic Enabled (0 = logic disabled, 1 = logic enabled)
