Necessary tools – Rockwell Automation 1770 DH,DHII,DH485 CABLE User Manual
Page 83
Planning a DH II Cable System
Chapter 5
5-7
You can order terminators from the following manufacturer:
Trompeter Electronics, Inc.
31186 Labaya Drive
Westlake, Village, CA 91311
The part numbers for the terminators are:
Component:
Manufacturer Part Number:
Plug connector
TNG1Ć1Ć150
Jack connector
TNGBJ1Ć1Ć150
For information on installing terminators, refer to Chapter 6.
To install a DH II cable system you will need a stripping and a crimping tool for
RG-11 cable. You may use the following tools, or equivalents:
Table 5.B
Recommended stripping and crimping tools.
Part
Manufacturer
Part Number
Crimping Tool
AMP
220015Ć1
Stripping Tool
Ideal Industries
45Ć164
These manufacturers can be contacted at the following addresses.
AMP Inc.
Harrisburg, PA 17105
Ideal Industries
4450 Becker Pl.
Sycamore, IL 60178
Necessary Tools
