Planning a DH II Cable System
Chapter 5
5-4
You must order RG-11 type coaxial cable through the following manufacturers.
Table 5.A
Manufacturers and part numbers for RGĆ11 type coaxial cable.
Manufacturer:
Part Number:
AllenĆBradley
94082901
Carol/Astro
C0996 / 20Ć111ĆE
Alpha
9825C
Times
AAĆ5066
For extremely harsh environments, order cable with a HALAR* jacket through
the following manufacturers.
Manufacturer: Part Number:
AllenĆBradley
400037401
Carol/Astro
20Ć111ĆH
*HALAR is a registered trademark of Ausimont Chemical.
These manufacturers can be contacted at the following addresses.
Allen-Bradley Company
747 Alpha Drive
Highland Heights, OH 44143
Alpha Wire Corp.
711 Lidgerwood Ave.
Elizabeth, NJ 07207
Carol/Astro Wire & Cable Corp.
50 Gardner St.
P.O. Box 246
Worchester, MA 01613
Times Fiber Communications Inc.
358 Hall Ave.
P.O. Box 384
Wallingford, CT 06492
For information on installing the trunkline, refer to Chapter 6.
