Preface
Publication 1775Ć10.1 - March 1996
Overview
This quick start is designed to help you quickly install and connect a
basic PLC-3 family programmable controller system. Use this guide
if you are knowledgeable about PLC-3 family products but may not
have used one or more of the products for a period of time. The
information we provide is geared to “jog your memory.”
b
step 1
2
3
step
step
a
b
a
Configure I/O chassis
(page 1Ć1)
Ground I/O chassis
(page 1Ć1)
a
b
Install 1775ĆP3 power supply
(page 2Ć1)
Install memory module(s)
(page 4Ć1)
Install I/O scanner module(s)
(page 4Ć2)
Install the processor module
(page 4Ć1)
Install 1775ĆP1 power supply
(page 2Ć3)
Connect front panel cable
(page 3Ć1)
For more information, see the PLCĆ3 Programmable Controllers
Installation and Operations Manual, publication 1775Ć6.7.1.
PLCĆ3
Controller
1775ĆS5
Scanner
1775ĆSR5
Scanner
PLCĆ3/10
Controller
DH +
Link
For more
information...
c
Configure processor chassis
(page 4Ć1)
c
d
Install I/O and Processor Chassis
Install Power Supply
Install Modules
Using this Quick Start
What You Need to Do
