4–2

Install, Wire, and Connect I/O

Publication 1775Ć10.1 - March 1996

Connect I/O

Connect the I/O scanner to the RIO adapters.

Line 1
Shield

Lin 2

Line 1
Shield

Lin 2

Line 1
Shield

Lin 2

Line 1
Shield

Lin 2

Channel

No. 4

Channel

No.2

Channel

No. 3

Channel

No.1

Blue

Shield
Clear

Blue

Shield

Clear

Blue

Shield
Clear

Blue
Shield
Clear

Terminator

(Cat. No. 1770-XT)

Optonal User-supplied

Pushbutton for

I/O Chassis Restart

Optonal User-supplied

Pushbutton for

I/O Chassis Restart

Terminator

(Cat. No. 1770-XT)

Twinaxial Cable

(Cat. No. 170-CD)

10,000 cable feet max.

I/O Adapter Module

Field Wiring Arm

I/O Adapter Module

Field Wiring Arm

I/O Scanner Module

Swing Arm
