3–2

Install Processor, Memory, and Scanner Modules

Publication 1775Ć10.1 - March 1996

Install I/O Scanner Module(s)

a

Set each thumbwheel switch to a unique number between 1 and 15.

b

You must have a scanner with the thumbwheel set for 1. If you are installing a

multiple chassis PLCĆ3 system, the scanner module whose thumbwheel you set

to 1 must be in the chassis with the front panel.

Set the necessary switches for your application of the scanner module.

For information about switch settings, see the user manual for your

particular scanner module. Some examples of switch settings for

scanner modules include backup options, DH+ communication,

station number identification, and termination.

For more
information...

c

Install the scanner module into any slot of the processor chassis.

!

ATTENTION:

Do not change the thumbwheel setting on a scanner

while power is on or equipment damage may result.
