A–2

Troubleshooting and Specifications

Publication 1775Ć10.1 - March 1996

Specifications for PLC-3/10 processors follow.

PLCĆ3/10 System
Dimensions

G

19 by 20 by 14.5¨ (483by508 by 368 mm)

mainframe and power supply

Mounting

G

Panel or 19 inch rack mount

I/O Capacity (per system)

G

2048 inputs and outputs (total, any mix)

G

2048 inputs and 2048 outputs (total,

complementary)

G

2 scanners (max)

Scan Time (nominal)

G

1 ms per 1K words of relayĆtype

instructions

G

2.5ms per 1K words (typical)

Memory

G

16, 32, 64 or 128K of Error Detecting and

Correcting (EDC) (128K maximum)

G

16 bits per word

Data Table Size

G

Expandable (limited only by available

memory)

Environmental Conditions

G

Operational Temperature: 32 to 140

°

F (0

to 60

°

C)

G

Storage Temperature: Ć40 to 185

°

F (Ć40

to 85

°

C)

G

Relative Humidity: 5 to 95% (without

condensation)

1775ĆP3 Power Supply
Input Voltage

G

115V AC

G

230V AC

Input Voltage Range

G

115V AC: 97 to 132V AC

G

230V AC: 194 to 264V AC

Input Current

G

115V AC: 3.0A @ 97V AC

G

230V AC: 1.5A @ 194V AC

Frequency Range

G

47 to 63Hz

Output Voltage @ Rated Current

G

+5V DC: 28A

"

16V DC: 1A (total)

Overcurrent Shutdown Limit

G

125% of rated current

Input Power

G

210W(nom)

Fuses

G

(2) 5A, 250 Volt, Slow Blow

Power Interlock Relay Contacts Rating

G

1A maximum, 250V maximum

Terminal Strip Wire Size

G

14AWG (max.)

External Transformer Rating (if used)

G

1000VA maximum (1 kVA)
