83 Publication 1757-UM007D-EN-P - December 2008 83
Chapter
8
Supported 1771 Modules
Introduction This chapter:
lists the supported 1771 modules.
describes module configuration, I/O Data, and diagnostic data.
Module Description The 1757-ABRIO module supports all digital 1771 modules and the
following 1771 block transfer modules. For information on how to
communicate with other block transfer I/O modules, see
Creating
Generic Modules in AbRioCfg Software on page 37 .
Refer to the corresponding pages in this chapter for information about
configuring these modules with the 1757-ABRIO module.
The AbRioCfg software handles the details of module configuration
using the parameters you supply. For applicable modules, the
1757-ABRIO module scales the raw data to floating point values using
optimal data resolution on the I/O module.
Supported modules
Module Description Page
1771-IFE Analog input module 84
1771-OFE Analog output module 89
1771-IR RTD input module 92
1771-IXE Thermocouple/millivolt module 95
1771-IL Analog input module 98
1771-NOC High resolution current output module 101
1771-NIV High resolution voltage input module 107
1771-NOV High resolution voltage output module 104
1771-NR RTD input module 110
