Publication 1757-UM007D-EN-P - December 2008 149
Appendix
D
Tag Descriptions for Scheduled Data in
RSLogix 5000 Software
When you create an exclusive owner or input only connection,
several tags are automatically created for the each 1757-ABRIO
module. For example, if your 1757-ABRIO module is located in the
supervisory rack, slot 3, then the configuration tag associated with it
would be Local:3:C.
Configuration Tag
The configuration tag gets created when you configure the
1757-ABRIO module as a 1756-MODULE, but the contents of the
configuration tag are not used by the 1757-ABRIO module.
I and O Tags
The I and O tags are associated with the digital I/O data. The input
tag also contains rack global status. The following tables show how
the tag contents correspond to the racks.
Generated Tag Extensions
Tag
Extension Description
C Configuration tag, created but not used
I Digital input data tag
O Digital output data tag
S Status tag
Input Tags
Address Description
Local::I.Data[0] Rack global status, 0 if all configured racks are
communicating with no errors, FFFF hex otherwise.
Local::I.Data[1] Rack global status, 0 if all configured racks are
communicating with no errors, FFFF hex otherwise.
Local::I.Data[2] Rack 1, I/O group 0 inputs
Local::I.Data[3] Rack 1, I/O group 1 inputs
...
Local::I.Data[9] Rack 1, I/O group 7 inputs
