152 Publication 1757-UM007D-EN-P - December 2008
Appendix C Tag Descriptions for Scheduled Data in RSLogix 5000 Software
Local::S.Data[3].8 Rack 6, I/O group 0 error
Local::S.Data[3].9 Rack 6, I/O group 2 error
Local::S.Data[3].10 Rack 6, I/O group 4 error
Local::S.Data[3].11 Rack 6, I/O group 6 error
Local::S.Data[3].12 Rack 7, I/O group 0 error
Local::S.Data[3].13 Rack 7, I/O group 2 error
Local::S.Data[3].14 Rack 7, I/O group 4 error
Local::S.Data[3].15 Rack 7, I/O group 6 error
Local::S.Data[4].0 Rack 10 octal, I/O group 0 error
Local::S.Data[4].1 Rack 10 octal, I/O group 2 error
Local::S.Data[4].2 Rack 10 octal, I/O group 4 error
Local::S.Data[4].3 Rack 10 octal, I/O group 6 error
Local::S.Data[4].4 Rack 11 octal, I/O group 0 error
Local::S.Data[4].5 Rack 11 octal, I/O group 2 error
Local::S.Data[4].6 Rack 11 octal, I/O group 4 error
Local::S.Data[4].7 Rack 11 octal, I/O group 6 error
Local::S.Data[4].8 Rack 12 octal, I/O group 0 error
Local::S.Data[4].9 Rack 12 octal, I/O group 2 error
Local::S.Data[4].10 Rack 12 octal, I/O group 4 error
Local::S.Data[4].11 Rack 12 octal, I/O group 6 error
Local::S.Data[4].12 Rack 13 octal, I/O group 0 error
Local::S.Data[4].13 Rack 13 octal, I/O group 2 error
Local::S.Data[4].14 Rack 13 octal, I/O group 4 error
Local::S.Data[4].15 Rack 13 octal, I/O group 6 error
Local::S.Data[5].0 Rack 14 octal, I/O group 0 error
Local::S.Data[5].1 Rack 14 octal, I/O group 2 error
Local::S.Data[5].2 Rack 14 octal, I/O group 4 error
Local::S.Data[5].3 Rack 14 octal, I/O group 6 error
Local::S.Data[5].4 Rack 15 octal, I/O group 0 error
Local::S.Data[5].5 Rack 15 octal, I/O group 2 error
Local::S.Data[5].6 Rack 15 octal, I/O group 4 error
Local::S.Data[5].7 Rack 15 octal, I/O group 6 error
Local::S.Data[5].8 Rack 16 octal, I/O group 0 error
Local::S.Data[5].9 Rack 16 octal, I/O group 2 error
Local::S.Data[5].10 Rack 16 octal, I/O group 4 error
Local::S.Data[5].11 Rack 16 octal, I/O group 6 error
Status Tag
Address Description
