Module info tab, Backplane tab, Module info tab backplane tab – Rockwell Automation 1757-ABRIO Process Remote I/O (RIO) Communication Interface Module User Manual
Page 141

Publication 1757-UM007D-EN-P - December 2008
139
Troubleshooting Appendix A
Module Info Tab
Backplane Tab
Item
Description
Vendor
Allen-Bradley
Product Type
Communications Adapter
Product Code
107
Revision
Matches the firmware revision level of the module.
Serial Number
Matches the serial number on the module
Product Name
57ABRIO
Status Section
contains information about the connection status, including:
Major fault
Minor fault
Internal state
Configured
Owned
Module Identity
Refresh
Updates information on the screen
Item
Description
ControlBus Status
displays backplane faults
ControlBus Parameters
The Multicast CRC error threshold is fixed at 8.
The Transmit Retry Limit defaults to 45 but can be edited.
Chassis
The Chassis area contains information that relates to the
chassis, not the module.
It contains the rack Revision, Serial Number, Size, and the
1757-ABRIO module slot number.
Error Counters
These refer to communications across the backplane.
They should all be 0.
Status
The Status at the bottom of the screen indicates the
status of the connection to the module.
