Rockwell Automation 1784-KTS_KTX_KTXD User Manual Communication Interface Card User Manual
Page 89
Use the KTx Card with 6200 Software
C-5
1784-6.5.22 - November 1999
7. Connect the appropriate cable from the card to the port on the programmable
controller:
• 1784-CP15 for PLC-2
• 1784-CP16 for PLC-3
8. Start 6200 software for the PLC-2 or PLC-3 programmable controller running
on the computer.
9. Go to on-line configuration and set the current device to:
• “1784-KT (Direct Con.)” for PLC-2 programmable controllers
• “1784-KT (BCL)” for PLC-3 programmable controllers
10. Set the address on the on-line configuration screen to the following bit
patterns, corresponding to the selections on the KTx card:
6200 PLC-2 and PLC-3 software supports only these addresses.
11. Save the configuration.
12. Go on line to confirm that everything is set correctly.
During subsequent programming sessions, these steps do not need
to be repeated.
•
010011 (CB00:)
•
001011 (D300:)
•
011011 (DB00:)
•
110011 (DF00:)
•
101011 (D700:)
•
111011 (DF00:)
