Connect the Interface Card 4-3
1784-6.5.22 - November 1999
Before You Begin
Before you make the connections, be certain that you have the correct cables.
This table lists the cables for various programmable controllers and processors:
For additional cable information, see these Allen-Bradley publications:
For: Use cable with
catalog number:
PLC-5/10, -5/12, -5/15, -5/25, -5/VME (6008-LTV) and
PLC-5/250 classic programmable controllers 1784-CP12
PLC-5/11, -5/20, -5/30, -5/40, -5/60, -5/80, and -5/VME
(1784-V40) enhanced programmable controllers
SLC 5/04 processors 1784-CP13
SLC 500 processors 1784-CP14
PLC-2 direct connect 1784-CP15
PLC-3 direct connect 1784-CP-16
DH-485 BELDEN #9842 (1) (2)
(1) Cables used for construction of custom cables
(2) Mating Connector: A-B PN 94199-06 or Phoenix Order No. 1849406
remote I/O / DH+ 1770-CD (1) (3)
(3) Mating Connector: A-B PN 941999-03 or Phoenix Order No. 1849396
Publication: Number:
1784-CP12 Cable Packing Data 1784-2.41
1784-CP13 Cable Packing Data 1784-2.44
1784-CP14 Cable Packing Data 1784-2.45
1784-CP15 Cable Packing Data 1784-2.43
1784-CP16 Cable Packing Data 1784-2.42
