What to do next, Terminate the last node -10, What to do next -10 – Rockwell Automation 1784-KTS_KTX_KTXD User Manual Communication Interface Card User Manual
Page 44: Terminate the last node
4-10
Connect the Interface Card
1784-6.5.22 - November 1999
Terminate the Last Node
You must terminate both ends of your DH+ network. If the KTx is the last node
on your network, you must set the switch on the CP14 to terminate the link as
shown below.
Refer to publication 1770-6.2.2, Data Highway/Data Highway Plus/Data
Highway II/Data Highway-485 Cable Installation Manual, for additional
information about cable issues.
What to Do Next
If you have read each chapter, completed the worksheets, run diagnostics, and
still have questions, please call Rockwell Automation Technical Support at
440.646.5800.
node not terminated
node terminated
6-pin Phoenix connector with
switchable termination resistor
42142
