Publication 1769-RM016A-EN-P - July 2006
46 Module Data, Status, and Configuration
1769-BOOLEAN Module
Configuration Data File The configuration file determines how the module will operate. Parameters
such as input filtering, output control mode, and Boolean expressions are set
up using this file. This data file is readable and writable. The default value of
the configuration file is all 0's.
1769-BOOLEAN Module Configuration Data File
BIT
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 Input Filter
1 IT_I7 EI_I7 IT_16 EI_I6 IT_I5 EI_I5 IT_I4 EI_I4 IT_I3 EI_I3 IT_I2 EI_I2 IT_I1 EI_I1 IT_I0 EI_I0
2 PFE
3
4 Program State
5 Program Value
6 Fault State
7 Fault Value
8 IT_O0 EI_O0 DB_0
9 Operand A 0
10 Operand B 0
11 Operand C 0
12 Operator_2_0 Operator_1_0
13 Output Delay 0
14 Output Duration 0
15
16 IT_O1 EI_O1 DB_1
17 Operand A 1
18 Operand B 1
19 Operand C 1
20 Operator_2_1 Operator_1_1
21 Output Delay 1
22 Output Duration 1
23
24 IT_O2 EI_O2 DB_2
25 Operand A 2
26 Operand B 2
27 Operand C 2
28 Operator_2_1 Operator_2_0
29 Output Delay 2
30 Output Duration 2
31
32 IT_O3 EI_O3 DB_3
33 Operand A 3
34 Operand B 3
35 Operand C 3
36 Operator_3_1 Operator_3_0
37 Output Delay 3
38 Output Duration 3
39
