Using the 1775ĆMX
Memory Communication Module
Chapter 4
4-4
Figure 4.1
LIST Menu for Primary and Backup Processor
SYSTEM MODE
1
TEST MONITOR
2 * RUN MONITOR
3 PROGRAM LOAD
4 * REMOTE ENABLE
5 SYSTEM STATUS
6 MODULE STATUS
ENTER NEXT >
MODULES
1 01 1775-ME8 A/A
2 01 1775-L3 A/E
3 01 1775-S5 A/G
4 01 1775-MX A/C
ENTER NEXT >
MCM OPERATION
CHASSIS 00 SLOT 06
SYSTEM ID. 03
LIST CONTROL
1
INACTIVE
2 * FILE TRANSFER
3 DATA TABLE XFER
4 MEMORY DOWNLOAD
5 LOCK SYSTEM
6 * UNLOCK SYSTEM
7 ENABLE PROG COMP
8 * DISABLE PROG COMP
9 FILE SELECTION
10 PROG COMP LIMITS
11 BACKUP TO PRIMARY DATA TRANS-
FER
ENTER NEXT >
FILE SELECTIONS
1
O0
2 I0
3 N23
4 D2
5 T0
6 C0
ENTER NEXT >
PROG COMP LIMITS
0=COMP DISABLED
MAIN
00004
SUBROUTINE 00003
FAULT 00000
THIS FEATURE CAN ONLY BE ENABLED/DISABLED WHEN SYS-
TEM IS IN PROGRAM MODE. THIS FEATURE MUST BE CONFI-
GURED IDENTICALLY IN BOTH THE PRIMARY AND BACKUP MX
MODULES.
ENTER E TO ENABLE THIS FEATURE OR D TO DISABLE IT.
10980ĆI
The MCM OPERATION menu shows you three things:
the source of control functions
selections made in LIST
present operational status of the memory communication module
Chassis and slot information appear directly beneath the title of the menu.
A system identification number, which is derived from the chassis and slot
numbers of scanner number one, is also shown.
