Publication 1757-UM002B-EN-P - January 2003
Import/Export 5-7
Translation Table declarations
Translation tables are defined at the end of the CSV file. Each table is created
with
BEGIN_TABLE and END_TABLE declarations. The table name and type
are declared with a TABLE line. The fields in a TABLE declaration are in
Table 5.D.
A TABLE_VAL statement declares each translation set in a table. The format
for this line type is specified in Table 5.E.
Since you can not browse the OPC server address space within the
ProcessLogix OPC Server (HWHsc.OPCServer); other methods have been
designed to implement this function.
Within the Control Builder program, you must export the current
configuration (or any desired tree level) that you need.
To export the current configuration, do the following:
1. Open Control Builder.
2. Select File ⇒ Export from the main menu to export the configuration or
the desired branch(es).
Table 5.D Translation Table Declarations
Field # FIELD NAME FIELD TYPE FIELD DESCRIPTION Examples
1 Line Type String Contains the string TABLE to define this line in the CSV
file as a Translation Table. TABLE
2 Table Name String Specifies the unique table Name of this configuration.
This field cannot contain any commas. User specified.
3 Table Type String Specifies the Table Type. The only table type currently
supported is DISCRETE.
DISCRETE
Table 5.E Table_val syntax
Field # FIELD NAME FIELD TYPE FIELD DESCRIPTION Examples
1 Line Type String Contains the string TABLE_VAL to
define this line in the CSV file as a
Translation Value Map. TABLE_VAL
2 ProcessLogix Dis-
crete Value Long Integer Specifies the discrete value on the Pro-
cessLogix Server side of the transla-
tion. 0
3 External Server Dis-
crete Value
Long Integer
Specifies the discrete value on the
External Server side of the translation.
1
