Rockwell Automation Publication 1609-QS002A-EN-P - May 2014 3
Preface
Overview
The 1609 Network Management Card is a device that can provide an interface between an Uninterruptible Power Supply
(UPS) and a network. It not only can communicate with a UPS and acquire its information, but it's also able to remotely
manage a UPS through a network system. This 1609-ENET card can support two kinds of protocols - SNMP and HTTP
for user access. Through the SNMP NMS and a Web Browser, you can easily obtain UPS status, and via a network, you can
effortlessly setup the 1609 Network Management Card.
UPS ENET Card Features:
• UPS network management: allow remote management of UPS from any workstation through the Internet or
Intranet
• UPS remote monitor via SNMP & HTTP: allow remote monitor of UPS via SNMP NMS together with UPS MIB
(Management Information Base) or via a Web Browser
• UPS and system function configuration from any client (password protected): allow to set UPS and system
parameters from a Web Browser
• Keep event log & metering data: provide the history data of UPS battery voltage and the event log of UPS status
• User notified via SNMP Trap and e-mail
• Support Network Time Protocol
• Support Telnet configuration
• Support BOOTP/DHCP
• Support security protocol - HTTPS, SSH, SFTP, and SNMPv3
• Login via RADIUS and local authentication
• Support syslog for keeping the event log remotely
• Support IPv4 and IPv6
• Support EtherNet/IP protocol
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at
http:/www.rockwellautomation.com/literature/ . To order paper copies of technical documentation, contact your local
Allen-Bradley distributor or Rockwell Automation sales representative.
Resource Description
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, http://www.ab.com Provides declarations of conformity, certificates, and other certification details.
Publication 1609-UM007_-EN-P Bulletin 1609 UPS Management software user manual
Publication 1609-UM009_-EN-P Bulletin 1609-B and -D Product User Manual
Publication 1609-IN012_-EN-P 1609-D Installation Instructions
Publication 1609-IN013_-EN-P 1609-B Installation Instructions
Publication 1609-IN014_-EN-P Surge Protective Device (Cat. No. 1609-SPD) Installation Instructions
Publication 1609-IN015_-EN-P Network Management Card (Cat. NO. 1609-ENET) Installation Instructions
