Rockwell Automation Publication 1609-QS002A-EN-P - May 2014 25
Appendix B EtherNet/IP Parameters
Appendix B – EtherNet/IP Parameters
Identity Object (0x01)
Attribute ID
Rule Name Data Type Description of Attribute
1 Get Vendor ID UINT Identification of each vendor
by number
2 Get Device Type UINT Indication of general type of product
3 Get Product Code UINT Identification of a particular product
of an individual vendor
4 Get Revision STRUCT of Revision of the item the Identity
Object represents
Major USINT
Minor USINT
5 Get Status WORD Summary status of device
6 Get Serial Number UDINT Serial number of device
7 Get Product Name SHORT_STRING Human readable identification
8 Get State USINT Present state of the device as
represented by the state transition
diagram
TCP/IP Interface Object (0xF5)
Attribute ID
Rule Name Data Type Description of Attribute
1 Get Status DWORD Interface status
2 Get Configuration
Capability DWORD Interface capability flags
3 Set Configuration Control DWORD Interface control flags
4 Get Physical Link Object STRUCT of Path to physical link object
Path size UINT Size of Path
Path Padded EPATH Logical segments identifying the
physical link object
5 Set Interface
Configuration STRUCT of TCP/IP network interface
configuration.
IP Address UDINT The device's IP address.
Network Mask UDINT The device's network mask
Gateway Address UDINT Default gateway address
Name Server UDINT Primary name server
Name Server 2 UDINT Secondary name server
Domain Name STRING Default domain name
6 Get/
Set Host Name STRING Host name
Ethernet Link Object (0xF6)
Attribute ID
Rule Name Data Type Description of Attribute
1 Get Interface Speed UDINT Interface speed currently in use
2 Get Interface Flags DWORD Interface status flags
3 Get Physical Address ARRAY of 6 USINTs MAC layer address
