Appendix A EtherNet/IP Object Service
Appendix A –EtherNet/IP Object Service
EtherNet/IP is an object orientated protocol. The Object Oriented structure
therefore allows for classes, instances, attributes and services. The ‘data types’
listed below are to be considered as the objects supported in the protocol. Each
of these has attributes that have been supported to differing degrees.
Object Name Class
code Description Service Support
Identity 0x01 Attributes Supported:
One instance supported (0x01)
Attributes List:
Details such as Appendix B
Services Supported:
Get_Attribute_All
Get_Attribute_Single
Reset
Message Router 0x02 Attributes Supported:
One instance supported (0x01)
Attribute List:
Max Connections Services Supported:
Get_Attribute_Single
Assembly 0x04 Attributes Supported:
Class Instance Support (0x00)
Class Attributes: 0x02 (Max Instance)
three instances supported (Input
0x30,Output 0x31 and Configure 0x32) Services Supported:
Get_Attribute_Single
Create (Instance)
Delete (Instance)
Insert_Member
Remove_Member
Connection
Manager 0x06 Forward Open Service
Forward Close Service
TCP/IP Interface
Object 0xF5 Attributes Supported:
One instance supported (0x01)
Attribute List:
Details such as Appendix B
Services Supported:
Get_Attribute_All
Get_Attribute_Single
Set_Attribute_Single
Ethernet Link
Object 0xF6 Attributes Supported:
One instance supported (0x01)
Attribute List:
Details such as Parameters Table
Physical Address Services Supported:
Get_Attribute_All
Get_Attribute_Single
UPS Object 0x377 Attributes Supported:
One instance supported (0x01)
Attribute List:
Details such as Appendix B
Services Supported:
Get_Attribute_Single
Set_Attribute_Single
