28 Rockwell Automation Publication 1609-QS002A-EN-P - May 2014
Appendix B EtherNet/IP Parameters
32 Required Get V TestResultsSummary INT
The results of the current or last UPS diagnostics
test performed. The values for donePass(1),
generalTestFail(3), and batteryTestFail(4) indicate
that the test completed either successfully, with a
warning, or with an error, respectively. Tests
which have not yet concluded are indicated by
inProgress(2). The value noTestsInitiated(0)
indicates that no previous test results are
available.
noTestsInitiated(0),
donePass(1),
inProgress(2),
generalTestFail(3),
batteryTestFail(4),
deepBatteryTestFail(5)
33 Required
Get V Alarm DWORD UPS Alarm status
off(0),on(1)
Disconnect bit 0 Does the UPS disconnect?
PowerFail bit 1 Does the input power fail?
BatteryLow bit 2 Are the UPS batteries low?
LoadWarning bit 3
Does the UPS load percent over the load warning
value?
TestInProgress bit 4 Does the UPS test in progress?
BatteryTestFail bit 5 Does the UPS test fail?
OutputOverload bit 6 Does the UPS output overload?
InverterAbnormal bit 7 Does the UPS inverter abnormal?
ReserveAbnormal bit 8 Does the UPS reserve abnormal?
OverTemperature bit 9 Does the UPS overheat?
OutputBad bit 10 Is the UPS output abnormal?
UPSOff bit 11 Is the UPS in standby mode?
ChargerFail bit 12 Does the UPS charger fail?
FanFail bit 13 Does the UPS fan fail?
OutputOff bit 14
Indicates whether the UPS output is turned off or
not
SmartShutdown bit 15
Indicates whether the Smart Shutdown is in
progress
UPSShutdown bit 16 UPS shutdown
Reserved bit 17-31 Reserved for future use and shall be set to zero
UPS Object (0x377)
Attribute ID Need
Access Rule NV Name Data Type Description of Attribute Semantics of value
