The Powermonitor 3000 is designed to connect easily to
industry-standard Ethernet hubs and switches using standard UTP
(unshielded twisted-pair) cables with RJ-45 connectors. Table 38
shows the cable and connector pin assignments and Figure 39 shows
a typical star network topology.
Table 37 Ethernet Hardware Versions
Series A Series B
Data Rate 10M Bit only 10/100M bit
Protocol Supported EtherNet/IP and CSP EtherNet/IP
Built-in Web Page Yes, fixed Yes, configurable
Supports CIP Class 1
Connnection (I/O Data) No Yes
Supports Control FLASH No Yes
Table 38 Ethernet Wiring Connections
Terminal Signal Function
1 TX+ TX+
2 TX- TX-
3 RX+ RX+
4
5
6 RX- RX-
7
8
