Page 22

3-2
Step 3 - Mount the Unit
1329I-5.5 Integrated Drive/Motor — January, 2000
3.2
Mounting Dimensions for NEMA Frames
Figure 3.1
NEMA Frame Mounting Dimensions
Frame Size
Dimensions in millimeters (inches)
A
2E
H
D
BF
AJ
AK
U
AH
S
ES
56C
170
(6.71)
140
(5.50)
8.6
(0.34)
89
(3.50)
16-3/8
149
(5.88)
114
(4.50)
15.9
(0.625)
52
(2.06)
4.8
(.19 SQ)
32
(1.25)
143TC
145TC
170
(6.71)
140
(5.50)
8.6
(0.34)
89
(3.50)
16-3/8
149
(5.88)
114
(4.50)
22.3
(0.875)
54
(2.12)
4.8
(.19 SQ)
32
(1.25)
182TC
184TC
216
(8.50)
191
(7.50)
8.6
(0.34)
114
(4.50)
13-1/2
184
(7.25)
216
(8.50)
28.6
(1.125)
67
(2.62)
6.4
(.25 SQ)
38
(1.50)
Frame Size
Dimensions in millimeters (inches)
BC
BB
BA
B
2F 1
2F 2
EV
C
P
BV
56C
4.8
(0.19)
3.0
(0.12)
70
(2.75)
165
(6.50)
76
(3.00)
127
(5.00)
12
(0.47)
404
(15.90)
213
(8.38)
258
(10.14)
143TC
3.0
(0.12)
3.0
(0.12)
70
(2.75)
165
(6.50)
102
(4.00)
127
(5.00)
12
(0.47)
418
(16.46)
213
(8.38)
258
(10.14)
145TC
3.0
(0.12)
3.0
(0.12)
70
(2.75)
165
(6.50)
102
(4.00)
127
(5.00)
12
(0.47)
405
(15.96)
213
(8.38)
270
(10.64)
182TC
3.0
(0.12)
6.4
(0.25)
89
(3.50)
165
(6.50)
114
(4.50)
140
(5.50)
13
(0.50)
476
(18.75)
224
(8.80)
315
(12.39)
184TC
3.0
(0.12)
6.4
(0.25)
89
(3.50)
165
(6.50)
114
(4.50)
140
(5.50)
13
(0.50)
502
(19.75)
224
(8.80)
340
(13.39)
45
°
D
2E
A
P
AJ
BF
H - Diameter Through
Face Runout and Eccentricity .004 Max. T.I.R.
Shaft Runout .002 Max. T.I.R.
S - Key Width/Height
ES - Key Length
3/4 Conduit
Both Sides
* Denotes Control Wiring Ports
** Denotes Input Power Port Opposite Side
B
C
BB
BV
6.00
AK
BA
2F 1
2F 2
EV
4.50
BC
AH
U
**
.75
8.01
*
