All parameters are specified at an input voltage of 24V, 10A output load, 25°C ambient and after a 5 minutes run-in time unless noted otherwise.
It is assumed that the input power source can deliver a sufficient output current.
Rockwell Automation Publication 1606-RM017A-EN-P — February 2014
17
Bulletin 1606 Switched Mode Power Supplies
17. EMC
The unit is suitable for applications in industrial environmental as well as in residential, commercial and light industry.
environment without any restrictions. The CE Mark is in conformance with EMC directive 89/336/EC and 93/68/EC &
2004/108/EC and the low-voltage directive (LVD) 73/23/EC, 93/68/EC, 2006/95/EC.
A detailed EMC Report is available on request.
EMC Immunity
EN 61000-6-1, EN 61000-6-2
Generic standards
Electrostatic discharge
EN 61000-4-2
Contact discharge
Air discharge
8kV
15kV
Criterion A*)
Criterion A *)
Electromagnetic RF field
EN 6100
0-4-3
80MHz-1GHz 10V/m
Criterion
A
Fast transients (Burst)
EN 61000-4-4
Out- and input lines
2kV
Criterion A
Signal lines **)
2kV
Criterion A
Surge voltage
EN 61000-4-5
Input + / - housing
500V
Criterion A
24V Output +
-
housing
500V Criterion
A
12V Output + / -
housing
500V Criterion
A
24V Output +
-
500V
Criterion A
Input + -
500V
Criterion A
Conducted disturbance
EN 61000-4-6
0,15-80MHz
10V
Criterion A
*)
DIN rail grounded
**) Tested
with
coupling
clamp
EMC Emission
EN 61000-6-3, EN 61000-6-4
Generic
standards
Conducted emission
EN 55022
Input lines
Class B *)
EN 55022
24V Output lines
Class B *)
EN 55022
12V Output lines
Class A *)
Radiated emission
EN 55011, EN 55022
Class B
This device complies with FCC Part 15 rules.
Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired operation.
*)
Informative measurement with voltage probe
Switching Frequencies
The DC-UPS has four converters with four different
switching frequencies included.
Switching frequency of boost converter
100kHz
Constant frequency
Switching frequency of electronic output current limitation
78kHz
Constant frequency
Switching frequency of battery charger
19.5kHz
Constant frequency
Switching frequency of step-down converter 12V output
40-55kHz
Depending on 12V output load
