Setup, Ethernet network addressing – Rockwell Automation 1408-EMxx PowerMonitor 1000 Unit User Manual
Page 45

PowerMonitor 1000 Unit 45
Rockwell Automation Publication 1408-IN001E-EN-P - September 2013
This feature applies to all models with catalog numbers ending in -ENT.
The Ethernet network port supports 10 or 100 Mbps data rate, half-duplex, or full-duplex.
Setup
The Ethernet network port is set up with a default IP address and gateway using a common
auto-configuration addressing scheme. The default address simplifies the task of making an
initial connection to the unit from a personal computer with a compatible Class B IP address.
The power monitor operates with a fixed IP address
that uniquely identifies it on the network.
An IP address of 255.255.255.255 is not permitted. The power monitor does not support
BOOTP or DHCP auto-addressing.
Ethernet Network Addressing
The IP address is a 32-bit binary number, which consists of the network address (NetID) and the
machine address (HostID). The Subnet mask
defines the boundary between the NetID and
HostID and each 0 represents the HostID.
Parameter
Description
Range
Default
User Setting
IP address bytes
1…4
Unit IP address in format
aaa.bbb.ccc.ddd
0…255
192.168.254.x
(x is the unit’s ID)
Subnet mask bytes
1…4
Subnet mask in format
aaa.bbb.ccc.ddd
0…255
255.255.0.0
Gateway IP address
bytes 1…4
Gateway IP address in
format aaa.bbb.ccc.ddd
0…255
128.1.1.1
SNTP setup
See
setup. Includes:
SNTP mode
Update interval
Time zone
Time server IP address
IMPORTANT
The IP address for your power monitor must not conflict with the IP address of any other device on the
network. Contact your network administrator to obtain a unique IP address, subnet mask, and default
gateway address for your unit.
Ethernet Network Addressing Example
IP address
(decimal):
192
1
1
207
(binary):
11000000
00000001
00000001
11001111
Subnet mask
(decimal):
255
255
255
0
(binary):
11111111
11111111
11111111
00000000
----
Net ID
----
-Host ID-
