Rockwell Automation 1502 Medium Voltage 400A Contactor - Series E User Manual
Page 11
Rockwell Automation Publication 1502-UM052H-EN-P - June 2013
11
Product Description
Chapter 1
Operational Characteristics
Mechanical Life (Operations) x 1000
(4)
Electrically Held
2500
Mechanical Latch
100
Electrical Life (Operations) x 1000
(4)
1000
Switching Frequency (Operations per hour)
Electrically Held
600
Mechanical Latch
150
Opening and Closing Times
Electro-Mechanical (Relay) Control (Mechanical Latch Only)
Maximum Closing Time (120 VAC)
50 or 60 Hz (milliseconds)
160
Maximum Opening Time (120 VAC)
50 or 60 Hz (milliseconds)
50
IntelliVAC and IntelliVAC Plus Control (Electrically Held & Mechanical Latch)
Maximum Closing Time (50 to 60 Hz)
120 / 240 VAC (milliseconds)
100 / 70
Maximum Opening Time
(without delay, for 50 to 60 Hz)
(5)
120 to 240 VAC (milliseconds)
60
Capacitor Switching (max. KVAR)
System Voltage
2400V
800
4160V
1400
6900V
2000
General
Standard Altitude Capability (meters / feet)
(1)(6)
-1000...5000 / 3300...16,500
Contactor Weight (kg / lbs)
21.8 / 48
Auxiliary Contact Rating
A600
Auxiliary Contacts on the Vacuum Contactor (Max.)
(7)
3 N.O. / 3 N.C.
(1) The voltage and current ratings listed are valid up to 1,000 m (3,300 ft). Please refer to
for ratings above this altitude.
(2) The IEC rating at 7200V (RMS Sym.) is 5300 A / 66 MVA.
(3) Control voltage, as measured at the input of the IntelliVAC or IntelliVAC Plus control module.
(4) Provided that regular maintenance is performed, as detailed in this manual.
(5) A contactor drop-out delay may be configured with the IntelliVAC or IntelliVAC Plus control module (refer to p
).
(6) The full Altitude range is available with the IntelliVAC or IntelliVAC Plus control module only, and the IntelliVAC or IntelliVAC Plus is to be configured accordingly (refer
to publications
he standard mechanical latch contactors, if used with electro-mechanical control, are designed
for -1000...1000 m (-3300...3300 ft). Higher altitudes are possible by changing the contactor return springs (refer to
for suitable catalog numbers).
(7) The number of contactor auxiliary contacts depends on the contactor type. Some of the contacts are used in the typical control schemes used.
Table 2 - Bulletin 1502 Medium Voltage 400 Amp Contactor Ratings (Continued)
