1336-5.39 – August, 1999
I-9
1336 PLUS Drives
The following is an explanation of the catalog numbering system for
1336 PLUS Common Bus AC Drives and options. The catalog
number is coded to identify the drive power rating and can be found
on the drive shipping carton and nameplate.
Catalog Number Explanation
1336S
– Use Number for
Specific Constant
Torque Drive
– BM – GM1 – HA1C . . .
BULLETIN
NO.
RATING-
ENCLOSURE
(MUST BE
SPECIFIED)
OPTIONS AS REQUIRED
Drive Rating
Enclosures
Open
IP00
No Enclosure
NEMA Type 1
IP20
General
Purpose
NEMA Type 4
IP56
Resist Water,
Dust
NEMA Type 12
IP54
Industrial Use
Frame
Designation
Constant Torque Variable Torque
Code Code Code Code
Output
Amps
Nominal
HP
Output
Amps
Nominal
HP
513 – 620V DC Input
D 85.0
106.0
138.0
173.0
60
75
100
125 96.0
120.0
150.0
180.0
75
100
125
150 R060-AN
R075-AN
R100-AN
R125-AN R060-AA
R075-AA
R100-AA
R125-AA Not available
Not available
Not available
Not available Not available
Not available
Not available
Not available
675 – 800V DC Input
D 85.0
109.0
138.0
75
100
125 85.0
109.0
138.0
75
100
125 W075-AN
W100-AN
W125-AN W075-AA
W100-AA
W125-AA Not available
Not available
Not available Not available
Not available
Not available
