Page 28: Figurei13
1336-5.39 – August, 1999
I-28
Ratings R150 – R250 and W150 – W250
Product Identification
Drive Nameplate Location
The drive nameplate is located on the face of the Control Board/
Adapter Mounting Plate. The drive nameplate contains the drive’s
catalog number and other important drive information. Reference the
catalog number to determine the rating of your drive, when calling for
technical assistance, and when ordering replacement parts.
Figure I-13
Drive Nameplate Location
AB0905
Nameplate located on top edge of
Control Board/Adapter Mounting
Plate.
