1336-5.39 – August, 1999
I-8
1336 IMPACT Drives
The following is an explanation of the catalog numbering system for
1336 IMPACT Common Bus AC Drives and options. The catalog
number is coded to identify the drive power rating and can be found
on the drive shipping carton and nameplate
Catalog Number Explanation
1336E
– Use Number for
Specific Constant
Torque Drive
– EN – L6 – HA1 – GM1
BULLETIN
NO.
RATING-
ENCLOSURE
(MUST BE
SPECIFIED)
LANGUAGE
MODULE
(MUST BE
SPECIFIED)
L-Option
(OPTIONAL)
HUMAN
INTERFACE
(OPTIONAL)
COMMUNICATION
CARD
(OPTIONAL)
Drive Rating
Enclosures
Open
IP00
No Enclosure
NEMA Type 1
IP20
General Purpose
NEMA Type 4
IP56
Resist Water, Dust
NEMA Type 12
IP54
Industrial Use
Frame
Designation
Output
Amps
Nominal
HP
Code Code Code Code
513 – 620V DC Input
D 96.9
120.3
149.2
180.4
60
75
100
125 R060-AN
R075-AN
R100-AN
R125-AN R060-AA, -AE
R075-AA, -AE
R100-AA, -AE
R125-AA, -AE Not available
Not available
Not available
Not available R060C-AJ
R075C-AJ
R100C-AJ
R125C-AJ
675 – 800V DC Input
D 85.8
109.1
138.6
75
100
125 W075-AN
W100-AN
W125-AN W075-AA
W100-AA
W125-AA Not available
Not available
Not available Not available
Not available
Not available
