PowerFlex 750-Series Power Option Cabinets
Table 13 - 690 Volt Light Duty Drives
Table 14 - 690 Volt Normal Duty Drives
Table 15 - 690 Volt Heavy Duty Drives
‡
The 6th character determines Enclosure Type & Depth. “B” = IP20, NEMA/UL Type 1, MCC style 600 mm (23.6 in.) deep. “L” = IP20,
NEMA/UL Type 1, MCC style 800 mm (31.5 in.) deep. Refer to the Power Wiring Options table.
Power
Frame
LD Amps Catalog Number
Bus Bar
Amps
Bus Bar Part Number
Minimum Qty of
20-75-PBAY-RBRK-2
Minimum Qty of
20-75-PBAY-LBRK-2
Minimum Qty of
20-75-PBAY-LBRK-4
315
8
330
20G1A‡F265AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
355
8
370
20G1A‡F330AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
400
8
410
20G1A‡F370AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
450
8
460
20G1A‡F415AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
500
8
500
20G1A‡F460AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
530
8
530
20G1A‡F500AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
630
9
650
20G11‡F590AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
710
9
710
20G11‡F650AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
800
9
790
20G11‡F710AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
850
9
860
20G11‡F765AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
900
9
960
20G11‡F795AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
1000
9
1020
20G11‡F960AN0NNNNN
1235
20-750-PBAY-RHBB-1235
2
2
1
1100
10
1150
20G11‡F1K0AN0NNNNN
1235
20-750-PBAY-RHBB-1235
2
2
1
1500
10
1485
20G11‡F1K4AN0NNNNN
1625
20-750-PBAY-RHBB-1625
2
2
1
Power
Frame
ND Amps Catalog Number
Bus Bar
Amps
Bus Bar Part Number
Minimum Qty of
20-75-PBAY-RBRK-2
Minimum Qty of
20-75-PBAY-LBRK-2
Minimum Qty of
20-75-PBAY-LBRK-4
250
8
265
20G1A‡F265AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
315
8
330
20G1A‡F330AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
355
8
370
20G1A‡F370AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
400
8
415
20G1A‡F415AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
450
8
460
20G1A‡F460AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
500
8
500
20G1A‡F500AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
560
9
590
20G11‡F590AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
630
9
650
20G11‡F650AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
710
9
710
20G11‡F710AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
750
9
765
20G11‡F765AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
800
9
795
20G11‡F795AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
900
9
960
20G11‡F960AN0NNNNN
975
20-750-PBAY-RHBB-975
2
2
1
1000
10
1040
20G11‡F1K0AN0NNNNN
1235
20-750-PBAY-RHBB-1235
2
2
1
1400
10
1400
20G11‡F1K4AN0NNNNN
1625
20-750-PBAY-RHBB-1625
2
2
1
Power
Frame
HD Amps Catalog Number
Bus Bar
Amps
Bus Bar Part Number
Minimum Qty of
20-75-PBAY-RBRK-2
Minimum Qty of
20-75-PBAY-LBRK-2
Minimum Qty of
20-75-PBAY-LBRK-4
200
8
215
20G1A‡F265AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
250
8
265
20G1A‡F330AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
300
8
308
20G1A‡F370AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
355
8
370
20G1A‡F415AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
375
8
375
20G1A‡F460AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
400
8
413
20G1A‡F500AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
450
9
460
20G11‡F590AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
500
9
500
20G11‡F650AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
560
9
590
20G11‡F710AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
630
9
650
20G11‡F765AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
710
9
750
20G11‡F795AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
800
9
795
20G11‡F960AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
900
10
865
20G11‡F1K0AN0NNNNN
975
20-750-PBAY-RHBB-975
1
1
1
1120
10
1160
20G11‡F1K4AN0NNNNN
1625
20-750-PBAY-RHBB-1625
2
2
1
