Chapter 5, Specifications, Electrical – Rockwell Automation 150-E SMC Elevator Users Manual User Manual
Page 27: Table 19 - power circuit, Chapter
Rockwell Automation Publication 150-UM009D-EN-P - February 2011
27
Chapter
5
Specifications
Electrical
Table 19 - Power Circuit
UL/cUL/CSA
IEC
Rated Operational Voltage 200…600V AC
200…500V~
Rated Insulation Voltage 600V AC
500V~
Di-electric Withstand 2200V AC
2500V~
Repetitive Peak 200…600V AC: 1600
500V~: 1600
Rated Impulse Voltage
6 kV
Overvoltage Category
III
Number of Poles
Equipment designed for 3-phase only
Operating Frequency
50/60 Hz
Controller Utilization Category 32/52/64
AC-53b: 3.5-15:3585
74/104/147
AC-53b: 4.5-30:1770
234
AC-53b: 3.5-30:1770
Overlad Current Range (Amps) Line
Delta
32
6.3...19
10.9...32.9
51
10...30
17...51
64
12.3...37
21.3...64
74
14.3...43
24.7...74
104 20...60
34.7...104
147 28.3...85
49...147
234 34...135
59...234
