Delta-connected controller, Figure 7 - typical control wiring – Rockwell Automation 150-E SMC Elevator Users Manual User Manual
Page 17
Rockwell Automation Publication150-UM009D-EN-P - February 2011
17
Installation & Wiring Chapter 2
Delta-Connected Controller
Figure 7 - Typical Control Wiring
➊ Customer supplied
SCPD
MOTOR
1
SMC
(power connections)
FC
FC
FC
L3 T5
L2 T4
L1 T6
E-STOP
FC
START
UTS
INDICATION
GROUND
ENABLE
A1 A2
SMC CONTROL TERMINALS
A1 A2 IN1 IN2 97 98 13 14
OVERLOAD/
FAULT
AUX#1
(UTS)
H3 H2
H1 H4
X1 X2
TRANS.
L1/1
L2/3
L3/5
T1/2
T2/4
T3/6
1
1
1
