Rockwell Automation 20-750-PBUS Profibus DPV1 Option Module User Manual
Page 77
Rockwell Automation Publication 750COM-UM004B-EN-P - September 2012
77
Option Module Parameters Appendix B
07
[Reset Module]
No action if set to ‘0’ (Ready). Resets the option
module if set to ‘1’ (Reset Module). Restores the
option module to its factory default settings if set
to ‘2’ (Set Defaults). This parameter is a command.
It will be reset to ‘0’ (Ready) after the command
has been performed.
When performing a Set Defaults, the drive may
detect a conflict. If this occurs, the drive will not
allow a Set Defaults action. You must resolve the
conflict before attempting a Set Defaults action for
the option module.
Default:
0 = Ready
Values:
0 = Ready
1 = Reset Module
2 = Set Defaults
Type:
Read/Write
Reset Required: No
08
[Net Data Format]
Displays the byte alignment for the network data
as selected with the Byte Swap switch 8 (see
Default:
0 = Ltl Endian
Values:
0 = Ltl Endian
1 = Big Endian
Type:
Read Only
09
[PROFIBUS Mode]
Displays the Profibus operation mode selected by
the user using the mode selection jumper (see
). This will be either Normal or PROFIdrive.
Important: PROFIdrive is not supported in this
version. It is reserved for future firmware update.
Values:
0 = Normal
1 = PROFIdrive
Type:
Read Only
10
[PROFIBUS Alarms]
Enables or disables generation of alarms on
Profibus.
Default:
0 = Enable
Values:
0 = Enable
1 = Disable
Type:
Read/Write
11
[DPV1 Map Mode]
Enables S7 Controller compatibility.
Default:
0 = Standard
Values:
0 = Standard
1 = S7 Comp
Type:
Read/Write
Parameter
No.
Name & Description
Details
ATTENTION: Risk of injury or equipment damage exists. If the option
module is transmitting I/O that controls the drive, the drive may fault
when you reset the option module. Determine how your drive will
respond before resetting the option module.
