Chapter 2 Installing the Option Module
Table 2 - Drive and Option Module Start-Up Status Indications
After verifying correct operation, swing down the drive HIM bezel to its closed
position and install the drive cover. For more details on status indicator
operation, see
page 66 and page 67 .
Item Name Color State Description
Drive STS Indicator
➊ STS
(Status) Green Flashing Drive ready but not running, and no faults are present.
Steady Drive running, no faults are present.
Yellow Flashing When running, a type 2 (non-configurable) alarm condition exists – drive
continues to run. When stopped, a start inhibit condition exists and the
drive cannot be started (see drive parameter 933 - [Start Inhibits]).
Steady A type 1 (user configurable) alarm condition exists, but the drive
continues to run.
Red Flashing A major fault has occurred. Drive will stop. Drive cannot be started until
fault condition is cleared.
Steady A non-resettable fault has occurred.
Red/Yellow Flashing
Alternately A minor fault has occurred. Use drive parameter 950 - [Minor Flt Config]
to enable. If not enabled, acts like a major fault. When running, the drive
continues to run. System is brought to a stop under system control. The
fault must be cleared to continue.
Yellow/Green Flashing
Alternately When running, a type 1 alarm exists.
Green/Red Flashing
Alternately Drive is updating.
Option Module Status Indicators
➋ PORT — Off The option module is not powered or connected properly to the drive.
Red Flashing The option module is not receiving any communication from drive.
Steady The option module detected a duplicate or invalid port ID.
Green Flashing The option module is establishing communication with drive.
Steady The option module is properly connected and communicating with drive.
Orange Steady The drive to which option module is connected is not an Allen-Bradley
brand.
➌ MOD — Off The option module is not powered or connected properly to the drive.
Red Flashing The option module has failed the firmware test or firmware update is in
progress.
Steady The option module has failed the hardware test.
Green Flashing The option module is operational but is not transferring I/O data.
Steady The option module is operational and is transferring I/O data.
➍ NET A — Off The option module cannot establish network communication or has
experienced a Communication Timeout.
Red Flashing The option module has detected a Network Configuration Error.
Steady The option module has experienced an internal network controller error
(Profibus ASIC Self-Test failure).
Green Steady The option module is properly connected and communicating over the
Profibus network.
